| Designed for vehicles up to | 5-5.5 M Srinter Van |
| Cooling capacity | 8.5 kW / 29,000 Btu/h / 7,300 kcal/h |
| Evaporator air flow | 2000 m3/h |
| Condenser air flow | 3200 m3/h |
| Dimension (l x w x h) | 1661x 1245 x 194mm |
| Power consumption (12V) | 40 A |
| Max ambient temperature | 50 °C |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Blower motor | 3-Speed centrifugal type |
| No. Of blower motor | 2 Pcs |
| Type | Micro-channel heating exchanger |
| Fan motor | Axial type |
| No. Of fan motor | 2 Pcs |
| Brand | Valeo |
| Model | TM-16 |
| Displacement | 163 cm³ ⁄ rev |
| Compressor oil type | ZXL 100PG PAG OIL (180 cm³) |
| Compressor weight | 4.9 kg (w/o clutch) |
