| Designed for vehicles up to | EV Bus 10 -12 M |
| Cooling capacity | 37.2 kW / 127,000 Btu/h / 32,000 kcal/h |
| Evaporator air flow | 6000 m3/h |
| Condenser air flow | 10000 m3/h |
| Fresh air volume | 1500 m3/h |
| Dimension (l x w x h) | 3000×1920×285 |
| Weight | 300 KGS |
| Power consumption (24V) | Max. 2.5 kW |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Blower motor | Speed by PWM centrifugal type |
| No. Of blower motor | 6 Pcs |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Fan motor | Speed by PWM axial type |
| No. Of fan motor | 5 Pcs |
| Brand | HIGHLY |
| Input voltage range | 400~750V DC |
| Compressor power consumption (HV) | 4 kW * 2 |
| Model | EV34* 2 |
| Displacement | 34 cc* 2 |
| Compressor oil type | HAF68 |
| Compressor weight | 7.5 kg * 2 |
| PTC | Optional |
